CNC Coordinate Measuring Machine

CNC Coordinate Measuring Machine

CNC Coordinate Measuring Machine
CategoriesCoordinate Measuring Machine
AlbumView larger image
BrandL&D
ModelCMM-554C
FOB portShenzhen
Terms of PaymentWestern Union, T/T, Paypal
Update Time2020-09-23
Detail Information

CNC Type Coordinate Measuring Machine




Usages


CMM-C series automatic Coordinate Measuring machine is widely used in the field of machinery, automobile, aviation, mould, metal and high-precision tool manufacturing, which can inspect the geometric dimension, shape and position of the box, guide rail, gear,   curve, cam and other work-pieces. This machine is necessary for CAD, CAE and CAM in reverse engineering.


Features


•   Monolithic granite table, unilateral moving bridge structure, optimize the movement performance and ensure the stability and precision of the mechanical systems

•   Three axes use the 000 level high-precision nature granite guides, so three-axis has the same temperature characteristics, good rigidity and anti-aging deformation

•   All guides use high-precision air bearings, with pre-press design and no abrasion, run more smoothly and ensure excellent dynamic performance of the machine

•   Z-axis pneumatic balance design to improve motion features

•   Adopt the RENISHAW self-adhesive strip of metal reflection grating scale, so that three axes have the same coefficient of expansion and enhance the stability of the equipment

•   Adopt UCC and PANTEC controller to improve the stability of operation and measurement efficiency

•   Adopt the high-precision RENISHAW probeWe provide various probes for option:
     MH20I Manual indexing Probe/TP20 Probe
     PH10T Motorized Indexing Head/TP20 Probe
     PH10M Motorized Indexing head/TP20 proe/SP25M Scanning probe

•   Adopt the JMC high quality air filter and regulator from Japan, which ensure that the machine can be used long-term stability

•   Powerful CMM software RationalDMIS provides the perfect solution for measurement, friendly interface, easy to learn and use


Specifications


Model
CMM-554C
CMM-665C
CMM-886C
CMM-10108C
CMM-574C
CMM-685C
CMM-8106C
CMM-10128C
CMM-584C
CMM-6105C
CMM-8126C
CMM-10158C
Travel
(mm)
X
500
600
800
1000
Y
500
700
800
600
800
1000
800
1000
1200
1000
1200
1500
Z
400
500
600
800
Driving System
Servo Motor
Control System
RENISHAW UCC Series with Joystick
Probing System
RENISHAW MH20I or PH10T+TP20
Measuring Software
RationalDMIS
Structure
Sliding Bridge Type
Guide
Air Bearing
Accuracy
(µm)
MPEE = ( 3.0 + L/250 )
MPEE = ( 3.5 + L/200 )
Resolution (µm)
0.5
Dimensions (m)
1.21 x 1.3 x 2.33
1.31 x 1.4 x 2.53
1.66 x 1.9 x 2.85
1.85 x 2.1 x 3.25
1.21 x 1.5 x 2.33
1.31 x 1.6 x 2.53
1.66 x 2.1 x 2.85
1.85 x 2.3 x 3.25
1.21 x 1.6 x 2.33
1.31 x 1.8 x 2.53
1.66 x 2.3 x 2.85
1.85 x 2.6 x 3.25
Weight (kg)
980
1100
2200
2600
1120
1250
2460
2880
1200
1400
2720
3300
Max.load (kg)
400
500
600
800
Package Dimensions (m)
1.3x 1.6 x 2
1.4 x 1.7 x 2.4
1.9 x 2.3 x 2.4
2.4 x 2.45 x 2.4
1.3 x 1.8 x 2
1.4 x 1.9 x 2.4
1.9 x 2.5 x 2.4
2.4 x 2.65 x 2.4
1.3 x 1.9 x 2
1.4 x 2.1 x 2.4
1.9 x 2.7 x 2.4
2.4 x 2.95 x 2.4
Environments
Power Supply
220 V ± 10%      50/60 Hz
Air Consumption
120L/min    at  0.4 MPa
Air Supply
³ 0.5 MPa
Temperature
18 ℃ -  22℃
Humidity
40%-70%
