Low Load Brinell Hardness Tester

Low Load Brinell Hardness Tester

Low Load Brinell Hardness Tester
CategoriesHardness Tester
AlbumView larger image
BrandL&D
ModelHBS-62.5
FOB portShenzhen
Terms of PaymentWestern Union, T/T, Paypal
Update Time2020-11-27
Detail Information

Main Function:

HBS-62.5 Digital Brinell hardness tester is a high-tech and new product combining the optics, mechanic and electrics features, with a novel and pleasing appearance, direct-viewing display, stable performance and good reliability, hence, it is an ideal instrument for the testing of low load Brinell hardness. The instrument has 8 steps test force and 9 kinds of Brinell testing scale for arbitrary selection; With 2 sets of objectives 5╳ and 10╳ both can be used for measurement; Automatic shifting between the objectives and the indenter; Pre-set the dwell time of test force and regulate the luminosity of light source; Automatically display the testing indentation length, hardness value and testing numbers; The test result can be printed out by the built-in printer and with RS232 interface for connecting to the computer; According to the client’s requirement, it can be equipped with video measuring device and CCD image automatic measuring system.



Application range:

Suitable for cast iron, steel products, nonferrous metals and soft alloys etc. Also suitable for some nonmetal materials such as rigid plastics and bakelite etc.



Technical Specification:

Model

HBS-62.5

Test Force

kgf

1kgf, 5kgf, 6.25kgf, 10kgf, 15.625kgf, 30kgf, 31.25kgf, 62.5kgf

N

9.807N, 49.03N, 61.29N, 98.07N, 153.2N, 294.2N, 306.5N, 612.9N

Test Range

3.18~653HBW

Hardness Resolution

0.1HBW

Data Output

Built-in Printer,RS232 Interface

Loading Method

Automatic (Loading/Dwell/Unloading)

Shifting between Objective and Indenter

Automatic Shifting

Eyepiece

10× Digital Measuring Eyepiece

Objective

5× ,10×

Total Magnification

50× ,100×

Effective Field of View

50×: 1.6mm,100×: 0.8mm

Min. Measuring Unit

50×: 0.5μm,100×: 0.25μm

Dwell Time

0~60s

Light Source

LED

Max. Height of Specimen

185mm

Throat

130mm

Power Supply

AC220V,50Hz

Execute Standard

ISO 6506,ASTM E10,JIS Z2243,GB/T 231.2

Dimension

530×280×630mm,

Packing Dimension: 620×450×760mm

Weight

Net Weight: 35kg,Gross Weight: 47kg



Packing List:

Name

Qty

Name

Qty

Instrument Main Body

1 set

10× Eyepiece

1 pc

5×、10× Objective

each 1 pc

Ф1mm, Ф2.5mm, Ф5mm  Ball Indenter

each 1 pc

Large Plane Test Table

1 pc

V-shaped Test Table

1 pc

Screw Driver

1 pc

Level

1 pc

Horizontal Regulating Screw

4 pcs

Hardness Block 90~120 HBW 2.5/62.5

1 pc

Hardness Block180~220 HBW 1/30

1 pc

Fuse 1A

2 pcs

Power Cable

1 pc

Inner Hexagon Spanner 2.5mm

1 pc

Anti-dust Cover

1 pc

Usage Instruction Manual

1 copy
