Portable Vibration Tester Machine with Aluminum shell
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | L&D |
| Certification: | CE |
| Model Number: | VM-600 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Piece |
|---|---|
| Price: | negotiation |
| Packaging Details: | Packed in aluminum plastic film firstly, and then reinforced with kraft carton case for outer packing |
| Delivery Time: | 4 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 50, 000PCS/Year |
|
Detail Information |
|||
| Accuracy: | 5% | Measuring Range: | 0.001~4.0mm |
|---|---|---|---|
| Power Supply: | 4x1.5V AAA(UM-4)Battery | ||
| High Light: | 90%RH Vibration Tester Machine,Handheld Vibration Tester Machine,10kHz digital vibration meter |
||
Product Description
Portable Vibration Tester Machine with Aluminum shell
Feature
* In accordance with ISO 2954, used for periodic measurements, to detect out-of-balance, misalignment and other mechanical faults in rotating machines.
* Specially designed for easy on site vibration measurement of all rotating machinery for quality control,commissioning, and predictive maintenance purposes.
* Individual high quality ccelerometer for accurate and repeatable measurements.
* Wide frequency range (10Hz~10kHz) in acceleration mode.
* Optional headphones for use as electronic stethoscope.
* Bearing condition monitoring function.
* Use USB/RS-232 data output to connect with PC.
* Provide Bluetooth data output choice.
Vibration Standard
| ISO/IS2373 Motor Quality Standard According As Vibration Velocity | ||||
| Quality Rank | Rev(rpm) | H:high of shaft(mm) Maximum vibration velocity rms(mm/s) |
||
| 80<H<132 | 132<H<225 | 225<H<400 | ||
| Normal | 600~3600 | 1.8 | 2.8 | 4.5 |
| Good(R) | 600~1800 | 0.71 | 1.12 | 1.8 |
| 1800~3600 | 1.12 | 1.8 | 2.8 | |
| Excellent(S) | 600~1800 | 0.45 | 0.71 | 1.12 |
| 1800~3600 | 0.71 | 1.12 |
1.8 |
|
Technical data
|
Sensor
|
Piezoelectric Transducer
|
|
|
Measuring Range
|
Acceleration
|
0.1~400m/s²Equivalent Park
|
|
Velocity
|
0.01~400mm/s True RMS
|
|
|
Displacement
|
0.001~4.0mm Equivalent Peak-peak
|
|
|
Frequency Range
|
Acceleration
|
10Hz~10kHz
|
|
Velocity
|
10Hz~1kHz
|
|
|
Displacement
|
10Hz~1kHz
|
|
|
Accuracy
|
5% of Reading+2 digits
|
|
|
Operating Conditions
|
Temperature
|
0~50ºC
|
|
Humidity
|
<90%RH
|
|
|
Power Supply
|
4x1.5V AAA(UM-4)Battery
|
|
|
Dimensions
|
124x62x30mm
|
|
|
Weight
|
120g(Not Including Batteries)
|
|
|
Standard Accessories
|
Main Unit
|
|
|
Piezoelectric Transducer
|
||
|
Powerful Rare Earth Magnet
|
||
|
Probe(Cone)&Probe(Spherical)
|
||
|
Carrying Case(B04)
|
||
|
Manual Book
|
||
|
Optional Accessories
|
Headset
|
|
|
RS-232C Data Cable with Software
|
||
|
Bluetooth Data Adapter with Software
|
||
