Standing-floor Phone Glass Optical Measurement Machine MPC500
Phone Glass Optical Measurement Machine
Usage
MPC series video measuring machine is suitable for all application fields with the purpose of two-dimensional coordinate measurement. It is widely used in precision machinery, electronics, instrumentation, plastics, mobile phone tablet, hardware mold, PCB, LCD, LED display and other industries.
Features & Advantages
■ High-precision marble base, table and column to ensure high stability and rigidity
■ Marble table design, with precision V-shaped cross rail, ensure long-term use without deform, effectively guarantee high mechanical precision
■ High-quality optical system and high-resolution CCD ensure sharp image edges
■ Three-ring and eight-zone LED ring surface cold light source and contour light source, avoid the deformation of precision parts caused by the heat from light
■ Optional fully automatic zoom lens, no need re-calibrate when changing magnification, save calibration time and avoid human error
■ Optional Renishaw contact probe for height, depth and other 3D measurement
■ Independent research and development of image measuring software, powerful and easy to operate
Technical data
| Model | MPC500 | |
| X,Y axis travel(mm) | 500*400 | |
| Stage glass size(mm) | 657*557 | |
| Z axis travel(mm) | 200 | |
| X,Y,Z axis resolution (μm) | 1 | |
| Length unit | Linear scale | |
| Measuring accuracy (μm) | 2.5+L/150 L=measuring length (mm) | |
| Operation method | Manual | |
| Camera | High resolution CCD camera | |
| Detent zoom lens | 0.7X~4.5X | |
| Video magnification | 27X~190X | |
| Object of view | 10.6mm~1.6mm | |
| Working distance | 90mm | |
| Measuring software | LeaderView 2D measuring software | |
| Illumination | Transmitted | LED ring light |
| Contour | LED light | |
| Power supply | AC100~240V 50/60Hz | |
