Low Load Brinell HBS-62.5 Digital Hardness Tester
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | HARDRULER |
| Certification: | CE |
| Model Number: | HBS-62.5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Piece |
|---|---|
| Price: | negotiation |
| Packaging Details: | Standard exporting package |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 50, 000PCS/Year |
|
Detail Information |
|||
| Measuring Range: | HB | Application: | Metal, Ceramics And Glass |
|---|---|---|---|
| Standard: | ISO, ASTM, GB/T | Calibrating Method: | Standard Hardness Test Blocks |
| Rated Voltage: | 110V/220V | Support Language: | English |
| Customized: | Customized | Testing Range: | Hbw8~Hbw650 |
| Loading Control: | Automatic(Loading, Dwell, Unloading) | Lens & Indenter Switch: | Motorized |
| Resolution: | 0.0005mm(5X) 0.00025mm(10X) | Dwell Time: | Adjustable 0~95s |
| Magnification Of Microscope: | Observation:5X/10X Measurement: 5X/10X | Magnification Of Eyepiece: | 10X, With Digital Encoder |
| Max. Height Of Specimen: | 170mm | HS Code: | 9024102000 |
| High Light: | Brinell HBS62.5 Digital Hardness Tester,HBS62.5 Digital Hardness Tester,HBS 62.5 Digital Hardness Testers |
||
Product Description
Low Load Brinell HBS-62.5 Digital Hardness Tester
Usage
HBS-62.5 low load Brinell hardness tester is used to determine the Brinell hardness of unquenched steel, cast iron, non-ferrous metals and soft bearing alloys, etc. It is especially suitable to determine the Brinell hardness of soft metal materials and small parts.
Features & Advantage
1. Accurate reliable and durable tester at a very cheap price
2. Closed loop load technology enhances the accuracy
3. Brinell video microscope system optional
4. Accuracy conforms to EN-ISO 6506, ASTM E10, GB/T231.2
Specifications
| Product name | Digital Low Load Brinell Hardness Tester | |
| Model | HBS-62.5M | |
| Brinell scales | HBW5/62.5, HBW2.5/62.5, HBW2.5/31.25, HBW2.5/15.625, HBW2.5/6.25, HBW1/30, HBW1/10, HBW1/5 | |
| Testing load | Kgf | 5, 6.25, 10, 15.625, 30, 31.25, 62.5 |
| N | 49.03, 61.29, 98.07, 153.2, 294.2, 306.5, 612.9 | |
| Testing range | HBW8~HBW650 | |
| Loading control | Automatic(loading, dwell, unloading) | |
| Lens & indenter switch | Motorized | |
| Resolution | 0.5μm(5x) 0.25μm(10x) | |
| Dwell time | Adjustable 0~95s | |
| Magnification of microscope | Observation:5x/10x measurement: 5x/10x |
|
| Magnification of eyepiece | 10x, with digital encoder | |
| Max. height of specimen | 170mm | |
| Instrument throat | 130mm | |
| Dimension (L*W*H) | 530*220*580mm | |
| Gross/Net weight | 70kg/50kg | |
| Power supply | 220V or 110V AC, 50 or 60Hz | |
| Accuracy | conforms to EN-ISO 6506, ASTM E10, GB/T231.2 | |
