    Motorized HBRV-187.5M Brinell, Rockwell and Vickers Hardness Testing Machine

    Product Details:

    Place of Origin: CHINA
    Brand Name: HARDRULER
    Certification: CE
    Model Number: HBRV-187.5M

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Piece
    Price: negotiation
    Packaging Details: Standard exporting package
    Delivery Time: 8 working days
    Payment Terms: L/C, T/T, Western Union, MoneyGram
    Supply Ability: 50, 000PCS/Year
    Get Best Price Contact Now

    Detail Information

    Application: Metal, Ceramics And Glass Standard: ISO, ASTM, GB/T
    Calibrating Method: Standard Hardness Test Blocks Rated Voltage: 110V/220V
    Support Language: English Customized: Customized
    Product Name: Universal Hardness Tester Product Type: Motorized
    Model: Hbrv-187.5m Hardness Parameters: Rockwell, Brinell, Vickers
    Optics: Eyepiece Magnification 15X Magnification Of Microscope: Brinell:37.5X; Vickers:75X
    Rockwell Test Loads: 60kgf(588.4n), 100kgf(980.7n), 150kgf(1471n) Brinell Test Loads: 31.25kgf(306.5n),62.5kgf(612.9n),187.5kgf(1839n)
    Vickers Test Loads: 30kgf(294.2n), 100kgf(980.7n) Rockwell Hardness Indication: Analogue Display
    HS Code: 9024102000 Port: Shenzhen, China
    High Light:

    Vickers Hardness Testing Machine

    ,

    187.5M Hardness Testing Machine

    ,

    Motorized vickers hardness tester

    Product Description

    Motorized HBRV-187.5M Brinell, Rockwell and Vickers Hardness Testing Machine

    Automatic Load Control Motorized Compound Hardness Tester (HBRV-187.5M)
    Usage
    Model HBRV-187.5M Compound Hardness Tester is compound type hardness gauge, which is suitable to determine Brinell, Rockwell and Vickers hardness of ferrous, non-ferrous metals and Hard alloy materials.
    Features & Advantage
    1. Universal Brinell, Rockwell and Vickers hardness tester
    2. Moving table between indenter and measuring microscope
    3. Magnification by objective lenses 37.5x and 75x


    Specifications

    Product nameMotorized Universal Hardness Tester
    ModelHBRV-187.5M
    Hardness parametersRockwell, Brinell, Vickers
    OpticsEyepiece magnification 15X
    Magnification of microscopeBrinell:37.5x; Vickers:75x
    Rockwell test loads60kgf(588.4N), 100kgf(980.7N), 150kgf(1471N)
    Brinell test loads31.25Kgf(306.5N),62.5Kgf(612.9N),187.5Kgf(1839N)
    Vickers test loads30Kgf(294.2N), 100Kgf(980.7N)
    Rockwell hardness indicationAnalogue display
    Rockwell resolution0.5HR
    Loading controlAutomatic
    Dwell time2-60S
    Magnification of microscopeBrinell:37.5x; Vickers:75x
    Max. height of specimenRockwell:170mm; Brinell, Vickers:140mm
    Instrument throat165mm
    Dimension (L*W*H)520 x215 x700mm
    Packing size630 x440 x960mm
    Gross/Net weight120kg/90kg
    Power supply220V or 110V AC, 50 or 60Hz
    AccuracyConforms to EN-ISO 6506 ,6507,6508, ASTM E18,ASTM E10 and ASTM E92, GB/T230.2, GB/T231.2, GB/T 4340.2


    Standard delivery

    Main unitThermal printerDiamond Rockwell indenter
    Vickers indenterRockwell ball indenter 1/16"Brinell ball indenter Ø2.5, Ø5mm
    Digital eyepiece 15xBrinell objective 2.5xVickers objective 5x
    Large flat anvil Ø150Small flat anvil Ø60V-anvil Ø40
    Hardness test blocksAdjustable feetAccessories case
    Anti-dust coverInstruments certificateInstallation & user manual
